3 Short-Range Comms & IoT Mode
3.3 LoRa (CSS) Demodulation Measurement
A delta marker is forced to Normal mode if you turn its reference off or if you move
its reference to another trace. (In the latter case the reference is not turned off even
if it is fixed.)
If you change the selected marker's reference (using the Marker, Properties, Relative
To), the selected marker is forced to Delta mode. This change of the selected marker
to Delta mode causes its new reference's control mode and position to change as
described above.
Delta Marker (Reset Delta)
The selected marker becomes a delta marker after this control being pressed. If the
selected marker is already a delta marker, its reference marker is moved to the exact
position of the selected marker, hence a reset.
Marker Table
When set to On, a marker data display window shows up in the display along with
the existing windows. For each marker that is on, its information is displayed therein,
which includes the marker number, the mode, the X axis scale, the X axis value, and
the Y-axis result, etc.
NOTE
Marker Table On/OFF control does not work on the quad view.
Remote Command
:CALCulate:LORA:MARKer:TABLe[:STATe] OFF | ON | 0 | 1
:CALCulate:LORA:MARKer:TABLe[:STATe]?
Example
:CALC:LORA:MARK:TABL ON
:CALC:LORA:MARK:TABL?
Preset
OFF
State Saved The on/off state of the Marker Table is saved in instrument state
Marker Settings Diagram
This diagram provides the users with a visualized way to configure the markers.
390 Short Range Comms & IoT Mode User's &Programmer's Reference
