3 Short-Range Comms & IoT Mode
3.7 ACP Measurement
Preset When "Max Num of Offsets" on page 902 is set to 12, the preset value of Offset G ~ L is the same as the
Offset F value
Modes Values
SA 2 MHz, 2 MHz, 2 MHz, 2 MHz, 2 MHz, 2 MHz|2 MHz, 2 MHz, 2 MHz, 2 MHz, 2
MHz, 2 MHz
WCDMA 3.84 MHz, 3.84 MHz, 3.84 MHz, 3.84 MHz, 3.84 MHz, 3.84 MHz|3.84 MHz, 3.84
MHz, 3.84 MHz, 3.84 MHz, 3.84 MHz, 3.84 MHz
LTEAFDD,
LTEATDD,
MSR
4.515 MHz, 4.515 MHz, 4.515 MHz, 4.515 MHz, 4.515 MHz, 4.515 MHz|4.5
MHz, 4.5 MHz, 4.5 MHz, 4.5 MHz, 4.5 MHz, 4.5 MHz
5G NR 98.28 MHz, 98.28 MHz, 98.28 MHz, 98.28 MHz, 98.28 MHz, 98.28 MHz|98.31
MHz, 98.31 MHz, 98.31 MHz, 98.31 MHz, 98.31 MHz, 98.31 MHz
Radio Test 25 kHz, 25 kHz, 25 kHz, 25 kHz, 25 kHz, 25 kHz
State Saved Saved in instrument state
Min/Max 10 Hz/Depends on instrument maximum frequency. Same as Max Span of the Swept SA Measurement
Backwards
Compatibility
SCPI
[:SENSe]:ACPower:OFFSet[1]|2:LIST:BWIDth[:INTegration]
[:SENSe]:ACPR:OFFSet[1]|2:LIST:BANDwidth
[:SENSe]:ACPR:OFFSet[1]|2:LIST:BWIDth
[:SENSe]:MCPower:OFFSet[1]|2:LIST:BANDwidth[:INTegration]
[:SENSe]:MCPower:OFFSet[1]|2:LIST:BWIDth[:INTegration]
Offset Side
Specifies which offset side to measure.
You can turn off (not use) specific offsets with [:SENSe]:ACPower:OFFSet[1]|2
[:OUTer]:LIST:SIDE.
NEGative
Negative (lower) sideband only
BOTH
Both of the negative (lower) and positive (upper) sidebands
POSitive
Positive (upper) sideband only
The figure below shows the relation between the negative/positive offset side setups
and the upper/lower results in MSR, LTEAFDD and LTEATDD Modes.
918 Short Range Comms & IoT Mode User's &Programmer's Reference
