3 Short-Range Comms & IoT Mode
3.9 Occupied BW Measurement
Example
:RAD:STAN ZIGB
:RAD:STAN?
Notes This setting was removed from GUI in XA25 because “Preset to Standard” was redesigned using
cascading list, thus all radio standards and the associated preset options are accessible at one time.
(prior to XA25, users need to select Radio Standard first, then select “preset to standard” which were
conditionally shown according to the selected radio standard)
The SCPI command is kept only for backward compatibility. Writing new SCPI script with this command
since XA25 is not recommendable. Using the SCPI command of “preset to standard” instead is advised
Couplings “Preset to Std” will set “Radio Standard” accordingly
Preset ZIGB
State Saved Yes
Range 802.15.4(ZigBee) | Z-Wave | LoRa CSS | 802.15.4(HUwb)
Standard Compatibility
ZigBee (IEEE 802.15.4)
Z-Wave (ITU-T G.9959)
LoRa
TM
CSS HRP UWB
Channel Power Yes Yes No
ACP Yes No No
SEM Yes No Yes
OBW Yes Yes No
Spurious Emissions Yes Yes No
CCDF Yes Yes No
IQ Waveform Yes Yes No
Monitor Spectrum Yes Yes No
Modulation Analysis (Digital) Yes No No
LoRa CSS Demod (Analog) No Yes No
Preset to Std
This group of controls lets you easily set up the analyzer for ZigBee (IEEE 802.15.4),
Z-Wave (ITU-T G.9959) , LoRa
TM
CSS or HRP UWB measurements.
Remote Command
[:SENSe]:RADio:STANdard:PRESet ZIGBEE2450 | ZIGBEE915 | ZIGBEE868 |
ZBOQPSK780 | ZBOQPSK915 | ZBOQPSK868 | ZWAVER1 | ZWAVER2 | ZWAVER3 | LORA7K
| LORA10K | LORA15K | LORA20K | LORA31K | LORA41K | LORA62K | LORA125K |
LORA203K | LORA250K | LORA406K | LORA500K | LORA812K | LORA1625K | HUWB500M
Example
:RAD:STAN:PRES ZIGBEE2450
Activates the preset for ZigBee 2450
Notes “Preset to Standard” was re-designed using cascading list dialog in XA25, thus all radio standards and
the associated preset options are accessible at one time (prior to XA25, users need to select Radio
1302 Short Range Comms & IoT Mode User's &Programmer's Reference
