3 Short-Range Comms & IoT Mode
3.7 ACP Measurement
Dependencies When "RBW Filter Type" on page 834 is Flattop, or "Res BW" on page 831 Mode for the offset is Auto,
this cell is grayed-out and disabled. Since Res BW Mode for the offset is preset to Auto on changing
"Meas Method" on page 863 to RBW, FAST or Fast Power, this cell is grayed-out and disabled too. If
the cell is pressed, an advisory message is generated. If the equivalent remote command is sent, a
"Setting conflict" warning is generated
Preset When "Max Num of Offsets" on page 902 is 12, the preset value of Offset G ~ L is DB3
DB3, DB3, DB3, DB3, DB3, DB3
State Saved Saved in instrument state
Range –3 dB (Normal)| –6 dB
Backwards
Compatibility SCPI
[:SENSe]:ACPower:OFFSet[1]|2:LIST:BWIDth:TYPE
Limits
Lets you configure the limits that are used to determine whether the offset regions
PASS or FAIL the limit test.
Limit Test
This checkbox is the same as "Limit Test" on page 882 in the Meas Setup, Settings
tab.
Offset Freq
This column is the same as "Offset Freq" on page 915 in the Offset index tab.
Abs Limit
Specifies an absolute limit value, which sets the absolute amplitude levels to test
against for each of the custom offsets. The list must contain 6 entries. If there is
more than one offset, the offset closest to the carrier channel is the first one in the
list. [:SENSe]:ACP:OFFSet[n][:OUTer]:LIST:TEST selects the type of testing to
be done at each offset.
You can turn off (not use) specific offsets with the [:SENSe]:ACP:OFFSet[n]
[:OUTer]:LIST:STATe command.
The query returns the six (6) sets of real numbers that are the current absolute
amplitude test limits.
Remote
Command
[:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:ABSolute < real>,…
[:SENSe]:ACPower:OFFSet[1]|2[:OUTer]:LIST:ABSolute?
882 Short Range Comms & IoT Mode User's &Programmer's Reference
