3 Short-Range Comms & IoT Mode
3.5 Channel Power Measurement
On the Meas Bar, the field “Atten” displays as follows:
–
If the sweep is entirely < 50GHz, the value shown after “Atten:” is equal to Mech Atten + Elec
Atten + Full Range Atten
–
If the sweep is entirely > 50GHz, the value shown after “Atten:” is equal to Full Range Atten
–
If the sweep straddles 50GHz, the value shown after “Atten:” is preceded by the symbol “>=” and
is equal to Full Range Atten
In the Amplitude, "Y Scale" on page 1633 menu, and the Atten Meas Bar dropdown menu panel, a
summary is displayed as follows:
“Total Atten below 50GHz” followed by the value of Full Range Atten + Mech Atten + Elec Atten
“Total Atten above 50 GHz” followed by the value of Full Range Atten
For example, if Mech Atten = 6dB, Elec Atten = 4dB, and Full Range Atten = 20dB, the summary
below is shown:
–
Attenuator summary:
–
Total Atten below 50GHz: 30dB
–
Total Atten above 50GHz: 20dB
Mech Atten
Labeled Mech Atten in Dual-Attenuator models, and Atten in Single-Attenuator
models. In the Dual-Attenuator configuration, this control only affects the
mechanical attenuator.
Lets you modify the attenuation applied to the RF input signal path. This value is
normally auto-coupled to Ref Level, "Internal Preamp" on page 1657 Gain, any
External Gain that is entered, and Max Mixer Level (if available), as described in the
table below.
See "Attenuator Configurations and Auto/Man" on page 562
Remote Command
[:SENSe]:POWer[:RF]:ATTenuation <rel_ampl>
[:SENSe]:POWer[:RF]:ATTenuation?
Example
:POW:ATT 20
Dual-Attenuator configuration: sets the mechanical attenuator to 20dB
Single-Attenuator mode: sets the main attenuation to 20dB (see below for definition of “main”
attenuation)
In either case, if the attenuator was in Auto, it is set to Manual
Dependencies Some measurements do not support Auto setting of Mech Atten. In these measurements, the
Auto/Man selection is not available, and the Auto/Man toggle function is not available
In Dual-Attenuator configurations, when the electronic attenuator is enabled, the mechanical
attenuator has no auto setting, and the Auto/Man toggle function is not available. The state of
560 Short Range Comms & IoT Mode User's &Programmer's Reference
