3 Short-Range Comms & IoT Mode
3.3 LoRa (CSS) Demodulation Measurement
Preset
ON
State Saved Saved in instrument state
Width
Sets the width of the X axis of the frequency drift window.
Remote Command
:DISPlay:LORA:WINDow6:TRACe:X[:SCALe]:WIDTh <real>
:DISPlay:LORA:WINDow6:TRACe:X[:SCALe]:WIDTh?
Example
:DISP:LORA:WIND6:TRAC:X:WIDT 1000
:DISP:LORA:WIND6:TRAC:X:WIDT?
Dependencies Changing the measure interval results in a change of Width. The value of Width will be changed to the
same value as that of the Meas Interval
Preset 100
State Saved Yes
Min/Max -9.9E+37 / 9.9E+37
3.3.9.3 Playback
This tab accesses controls for setting the parameters of playback.
See the Save chapter and Recall chapter under Recording for more information on
how to load and save Recording files.
See the Sweep chapter under Recording for more information about how to manage
and play recordings.
Playback Start
Specifies the start position of the IQ data playback range to be analyzed. When its
value < 0, additional zero will be insert at the beginning of IQ data.
Remote Command
:CALCulate:LORA:PLAY:STARt <time>
:CALCulate:LORA:PLAY:STARt?
Example
:CALC:LORA:PLAY:STAR 0.01 s
:CALC:LORA:PLAY:STAR?
Preset 0
State Saved Saved in instrument state
Min Sample Points in IQ file x Sample Rate
Max Sample Points in IQ file / Sample Rate in IQ file
Short Range Comms & IoT Mode User's &Programmer's Reference 427
