3 Short-Range Comms & IoT Mode
3.11 IQ Waveform Measurement
Interval Function
Sets the marker control function type to one of:
Option Parameter
Marker Noise
NOISe
Interval Power
BPOWer
Interval Density
BDENsity
Marker Function Off
OFF
All interactions and dependencies detailed under the control description are
enforced when the remote command is sent.
Remote
Command
:CALCulate:WAVeform:MARKer[1]|2|…|12:FUNCtion NOISe | BPOWer | BDENsity | OFF
:CALCulate:WAVeform:MARKer[1]|2|…|12:FUNCtion?
Example
:CALC:WAV:MARK:FUNC BPOW
:CALC:WAV:MARK:FUNC?
Preset
OFF
State Saved Saved in instrument state
Range Marker Noise | Interval Power | Interval Density | Off
Annotation Mkr # <X value> and <Marker value> upper right on graph
Interval Span
Sets the width of the Span for the selected marker.
Remote
Command
:CALCulate:WAVeform:MARKer[1]|2|…|12:FUNCtion:BAND:SPAN <time>
:CALCulate:WAVeform:MARKer[1]|2|…|12:FUNCtion:BAND:SPAN?
Example
:CALC:WAV:MARK:FUNC:BAND:SPAN 20 ms
:CALC:WAV:MARK:FUNC:BAND:SPAN?
Couplings Changing Interval Span necessarily changes "Interval Left" on page 1589 and "Interval Right" on page
1590
Preset 10% of Meas Time
State Saved Saved in instrument state
Min 0
Max 100 s
Interval Left
Sets the left edge time for the band of the selected marker.
Short Range Comms & IoT Mode User's &Programmer's Reference 1589
