6 Input/Output
6.8 Trigger Output
Option details
Here are details of all Source PXI Trigger Output options:
Source SCPI Notes
Off
OFF
Selects no signal to be output to the Source PXI backplane line
Source
Marker 1
S1Marker
Selects the Trigger Output at Marker 1 in the Waveform file that is currently playing to be
output to the Source PXI backplane line
Source
Marker 2
S2Marker
Selects the Trigger Output at Marker 2 in the Waveform file that is currently playing to be
output to the Source PXI backplane line
Source
Marker 3
S3Marker
Selects the Trigger Output at Marker 3 in the Waveform file that is currently playing to be
output to the Source PXI backplane line
Source
Marker 4
S4Marker
Selects the Trigger Output at Marker 4 in the Waveform file that is currently playing to be
output to the Source PXI backplane line
PerArb
PARB
A synchronization trigger that is generated by the ARB at the beginning of each repetition
of playing the signal. This selection causes the PerArb Trigger Output that is currently
playing to be output to the Source PXI backplane line
Only available in VXT Models M9410A/11A/15A/16A and M9410E/11E/15E/16E
6.8.5 Src Trig Out Polarity
Sets the output to the Source PXI backplane trigger line to trigger on either the
positive or negative polarity.
Remote Command
:TRIGger:PXIE:SOURce[:SEQuence]:OUTPut:POLarity POSitive | NEGative
:TRIGger:PXIE:SOURce[:SEQuence]:OUTPut:POLarity?
Example
:TRIG:PXIE:SOUR:OUTP:POL POS
Dependencies Only appears in EXM, VXT and M941xE
Preset Unaffected by Preset, but set to POSitive by Restore Input/Output Defaults or Restore System
Defaults->All
State Saved Saved in instrument state
6.8.6 Select Src PXI Line
Controls which backplane trigger line TRIG[0…7] is used for the Source Trigger
Output.
Remote Command
:TRIGger:PXIE:SOURce[:SEQuence]:OUTPut:LINE <line>
:TRIGger:PXIE:SOURce[:SEQuence]:OUTPut:LINE?
2173 Short Range Comms & IoT Mode User's &Programmer's Reference
