Keysight x-series Instruction Manual

6 Input/Output
6.1 RF Source
Auto Function
Remote
Command
:SOURce:RADio:ARB:TRIGger[:SOURce]:PXI:DELay:STATe OFF | ON | 0 | 1
:SOURce:RADio:ARB:TRIGger[:SOURce]:PXI:DELay:STATe?
Example
:SOUR:RAD:ARB:TRIG:PXI:DEL:STAT ON
:SOUR:RAD:ARB:TRIG:PXI:DEL:STAT?
Preset
OFF
PXI Trigger Polarity
Sets the polarity of the PXI trigger:
–
When POSitive is selected, trigger event happens on a rising edge of the PXI
trigger in signal
–
When NEGative is selected, trigger event happens on a falling edge of the PXI
trigger in signal
Active only if "Trigger Source" on page 1988 is PXI.
Remote Command
:SOURce:RADio:ARB:TRIGger[:SOURce]:PXI:SLOPe POSitive | NEGative
:SOURce:RADio:ARB:TRIGger[:SOURce]:PXI:SLOPe?
Example
:SOUR:RAD:ARB:TRIG:PXI:SLOP POS
:SOUR:RAD:ARB:TRIG:PXI:SLOP?
Dependencies Unavailable and grayed-out when "Trigger Source" on page 1988 is PXI
Not available in E7760B
Preset
POSitive
Range
POSitive|NEGative
I/Q Adjustments
Enables or disables the I/Q adjustments.
Remote Command
:SOURce:RADio:ARB:IQADjustment:[STATe] OFF | ON | 0 | 1
:SOURce:RADio:ARB:IQADjustment:[STATe]?
Example
:SOUR:RAD:ARB:IQAD ON
:SOUR:RAD:ARB:IQAD?
Dependencies Not available in E7760B
Preset
OFF
Short Range Comms & IoT Mode User's &Programmer's Reference 1994
