3 Short-Range Comms & IoT Mode
3.11 IQ Waveform Measurement
as shown below.
Remote Command
:CALCulate:WAVeform:MARKer:PEAK:SEARch:RANGe:STOP <time>
:CALCulate:WAVeform:MARKer:PEAK:SEARch:RANGe:STOP?
Example
:CALC:WAV:MARK:PEAK:SEAR:RANG:STOP 0.001
Dependencies Disabled when Peak Search Range is set to Full.
Preset 0.0 ms
Min/Max 0.0/+Meas Time
3.11.7.5 Marker Function
The controls in this tab perform post-processing operations on marker data.
The Marker Function menu controls which marker functions are turned on, and
allows you to adjust the setup parameters for each function. These parameters
include the following, but only one parameter can be assigned to a given marker:
–
Marker Noise
–
Interval Power
–
Interval Density
–
Off
More Information
In the Waveform measurement, post-processing operations on markers are based
on the measurement specifications. Marker Functions are distinct from
measurement functions, which automatically perform complex sequences of setup,
data acquisition, and display operations, to measure specified signal characteristics.
Marker Functions are specified for each individual marker, and may be turned on
individually for each marker.
Marker Time
This is the fundamental control that you use to move a marker around on the trace.
It is the same as "Marker Time" on page 1581 in Settings.
1588 Short Range Comms & IoT Mode User's &Programmer's Reference
