6 Input/Output
6.5 Corrections
6.5.6 Edit Correction Settings
Opens another menu page that lets you set certain properties of the selected
correction, such as Interpolation, Transducer Unit, Description and Comment.
6.5.6.1 Select Correction
Specifies the selected correction. The term "selected correction" is used throughout
this document to specify which correction will be affected by the functions.
Notes The selected correction is remembered even when not in the correction menu
Preset Set to Correction 1 by Restore Input/Output Defaults
6.5.6.2 Freq Interpolation
Controls how the correction values per-bucket are calculated. We interpolate
between frequencies in either the logarithmic or linear scale.
This setting is handled and stored individually per correction set.
VXT models M9410A/11A/15A/16A only support Linear Interpolation. For more
details, see "Interpolation" on page 2122
Remote
Command
[:SENSe]:CORRection:CSET[1]|2|…|16:X:SPACing LINear | LOGarithmic
[:SENSe]:CORRection:CSET[1]|2|…|16:X:SPACing?
Example
:CORR:CSET:X:SPAC LIN
Preset Unaffected by Preset. Set to Linear by Restore Input/Output Defaults
State Saved Saved in instrument state
Interpolation
For each bucket processed by the application, all of the correction factors at the
frequency of interest (center frequency of each bucket) are summed and added to
the amplitude. All trace operations and post processing treat this post-summation
value as the true signal to use.
To effect this correction, the goal, for any particular start and stop frequency, is to
build a correction trace, whose number of points matches the current Sweep Points
setting of the instrument, which will be used to apply corrections on a bucket-by-
bucket basis to the data traces.
Short Range Comms & IoT Mode User's &Programmer's Reference 2122
