3 Short-Range Comms & IoT Mode
3.11 IQ Waveform Measurement
Next Peak
Moves the selected marker to the peak that is next lower in amplitude than the
current marker value.
If the selected marker was OFF, then it is turned ON as a POSition marker, and a
peak search is performed.
Remote Command
:CALCulate:WAVeform:MARKer[1]|2|…|12:MAXimum:NEXT
Example
:CALC:WAV:MARK:MAX:NEXT
Notes Sending this command selects the subopcoded marker
State Saved Not part of saved state
Minimum Peak
Moves the selected marker to the minimum Y-Axis value on the current trace.
If the selected marker is OFF, it is turned ON before the minimum search is
performed.
Remote Command
:CALCulate:WAVeform:MARKer[1]|2|…|12:MINimum
Example
:CALC:WAV:MARK:MIN
Notes Sending this command selects the subopcoded marker
State Saved Not part of saved state
Marker Delta
Pressing this control has the same effect as pressing Delta in "Marker Mode" on
page 1583 on the Settings tab. The selected marker becomes a Delta marker. If the
selected marker is already a Delta marker, the reference marker is moved to the
current position of the selected marker, thus resetting the delta to zero.
The control is duplicated here to allow you to conveniently perform a Peak Search
and change the marker’s control mode to Delta, without having to access two
separate menus.
3.11.7.4 Pk Search Config
Contains controls that let you set up the Peak Search functions.
Since the Pk Search Config functions are independent of the selected Marker, the
Select Marker control does not appear while in Pk Search Config.
1586 Short Range Comms & IoT Mode User's &Programmer's Reference
