3 Short-Range Comms & IoT Mode
3.2 Modulation Analysis Measurement
3.2.1 Views
The Modulation Analysis measurement has five pre-defined views – "Normal" on
page 188 view, "Demod Traces" on page 188 view, "Demod Error" on page 188 view
and "Decode" on page 189 view and "Result Summary" on page 189 view.
Some of these Views are multiple-window Views. When in a multiple window View,
you select a window by touching it. The menu controls may sometimes change
depending on which window is selected.
Whenever the View changes, the default menu is Frequency, unless otherwise
specified in the View description.
View – Selection by Enum (Remote Command Only)
Remote
Command
:DISPlay:EVM:VIEW[:SELect] NORMal | DTRace | DERRor | DECode | NRESults
:DISPlay:EVM:VIEW[:SELect]?
Example
:DISP:EVM:VIEW NORM
sets the normal view
Preset NORM
State Saved Saved in instrument state
3.2.1.1 Normal
Windows: "IQ Meas Time" on page 191, "Raw Main Time" on page 191, "Spectrum"
on page 191, "Metrics" on page 197
Multiple windows view consists of the above four windows.
Example
:DISP:EVM:VIEW NORM
3.2.1.2 Demod Traces
Windows: "IQ Meas Spectrum" on page 193, "IQ Meas Time" on page 191
Dual windows view consists of the above two windows.
Example
:DISP:EVM:VIEW DTR
3.2.1.3 Demod Error
Windows:"Mag Error" on page 195, "Phase Error" on page 196, "Error Vector Time"
on page 195, "Metrics" on page 197
188 Short Range Comms & IoT Mode User's &Programmer's Reference
