Keysight x-series Instruction Manual

9 Programming the Instrument
9.4 Status Register System & STATus Subsystem
Questionable Calibration Negative Transition
Determines which bits in the "Questionable Calibration Condition" on page 2485
register will set the corresponding bit in the "Questionable Calibration Event Query"
on page 2486 register when the condition register bit has a negative transition (1 to
0).
The variable <integer> is the sum of the decimal values of the bits that you want to
enable.
Remote
Command
:STATus:QUEStionable:CALibration:NTRansition <integer>
:STATus:QUEStionable:CALibration:NTRansition?
Example
:STAT:QUES:CAL:NTR 16384
“Align All Now Needed” being cleared will be reported to the Calibration Summary of the Status
Questionable register
Preset 0
Min 0
Max 32767
Status Bits/OPC
dependencies
Sequential command
Questionable Calibration Positive Transition
Determines which bits in the "Questionable Calibration Condition" on page 2485
register will set the corresponding bit in the "Questionable Calibration Event Query"
on page 2486 register when the condition register bit has a positive transition (0 to
1).
The variable <integer> is the sum of the decimal values of the bits that you want to
enable.
Remote
Command
:STATus:QUEStionable:CALibration:PTRansition <integer>
:STATus:QUEStionable:CALibration:PTRansition?
Example
:STAT:QUES:CAL:PTR 16384
“Align All Now Needed” being set will be reported to the Calibration Summary of the Status
Questionable register
Preset 32767
Min 0
Max 32767
Status Bits/OPC
dependencies
Sequential command
2487 Short Range Comms & IoT Mode User's &Programmer's Reference
