7 Save/Recall/Print
7.2 Recall
where <mode name> is the parameter used to select the mode with :INST:SEL (for
example, MRECEIVE for Measuring Receiver Mode). Hence, a Cal Factor file from any
measurement in the Measuring Receiver mode would be stored in:
My Documents\MRECEIVE\data\PSCF
Cal Factor files have the extension .xml. The default filename is <Sensor Model>_
<Sensor Serial Number>_0000.xml, where the 4-digit number is the lowest
number that does not conflict with any filename in the current directory. If the
sensor model or serial number is blank, the default filename is PSCF_0000.xml.
Remote Command
:MMEMory:STORe:PSCFactor <file_name>
Example
:MMEM:STOR:PSCF "myPSCF.xml"
Notes If the save is initiated via SCPI, and the file already exists, the file will be overwritten
Using the C: drive is strongly discouraged, since it runs the risk of being overwritten during an
instrument software upgrade
Both single and double quotes are supported for any filename parameter over SCPI
Dependencies Only appears if you have the proper option installed in your instrument
7.2.31 Recording
Lets you specify a data type (for example, I/Q data) and select a file from which to
import the data, then the data can be routed to the measurement engine as though
it were being acquired from the Input.
The recording and playback of signal data files is a multi-step process that involves
controls in several menus.
The menus that are involved in Record/Playback are:
–
Save, "Recording" on page 2303 (under the Save hardkey or the Save icon in the
File panel)
–
Recall, Recording (this menu)
–
Sweep, Recording tab
–
Sweep, Playback tab
–
Input/Output, "Data Source" on page 2101 tab
NOTE
A complete tutorial for the Record/Playback functionality, including how to load
and save Recording files, can be found under the Data Source tab in
Input/Output.
Dependencies Only available in the following modes and measurements:
2244 Short Range Comms & IoT Mode User's &Programmer's Reference
