3 Short-Range Comms & IoT Mode
3.9 Occupied BW Measurement
Command
:CALCulate:OBWidth:MARKer[1]|2|…|12:X:POSition?
Example
:CALC:OBW:MARK10:X:POS 0
:CALC:OBW:MARK10:X:POS?
Notes The query returns the marker’s absolute X-Axis value in trace points if the control mode is Normal, or
the offset from the marker’s reference marker in trace points if the control mode is Delta. The value is
returned as a real number, not an integer, corresponding to the translation from X-Axis Scale units to
trace points . When a marker is turned on, it is placed center of the screen on the trace. Therefore, the
default value depends on instrument condition
If the marker is Off, the query response is Not A Number
Preset After a preset, all markers are turned Off, so the query returns Not A Number (NAN)
State Saved Saved in instrument state
Min -9.9E+37
Max 9.9E+37
Marker Y Axis Value (Remote Query only)
Returns the marker Y-Axis value in the current marker Y-Axis unit.
Remote
Command
:CALCulate:OBWidth:MARKer[1]|2|…|12:Y?
Example
:CALC:OBW:MARK11:Y?
Notes Returns the marker Y-Axis result, if the control mode is Normal or Delta
If the marker is Off, the response is Not A Number
Preset Result dependent on Markers setup and signal source
State Saved No
Backwards
Compatibility
SCPI
:CALCulate:OBWidth:MARKer[1]|2|…|12:FUNCtion:RESult?
Marker Mode
Sets the marker control mode to Normal (POSition), Delta, or Off. All interactions
and dependencies detailed under the control description are enforced when the
remote command is sent. If the selected marker is OFF, pressing Marker sets it to
Normal and places it at the center of the screen on the trace determined by the
Marker Trace rules. At the same time, Marker X Axis Value appears on the Active
Function area.
The default active function is the active function for the currently selected marker
control mode. If the current control mode is Off, there is no active function, and the
active function is turned off.
1288 Short Range Comms & IoT Mode User's &Programmer's Reference
