3 Short-Range Comms & IoT Mode

3.11 IQ Waveform Measurement

Min/Max 1.000 us/100.0 s

1.000 us/3200 s

Sample Rate

Sets an arbitrary sample rate for the acquired data to be processed.

Remote Command

[:SENSe]:WAVeform:SRATe <freq>

[:SENSe]:WAVeform:SRATe?

Example

:WAV:SRAT 1.3636 MHz

Notes The command and query are available when Option DP2, B40, or wider IF Bandwidth option is

installed. For other configurations, only the query is available

Dependencies To set a 2.4 GHz Sample Rate with Options R15 or R20, Center Frequency must be greater than or

equal to 3.5 GHz

To set a 5.1 GHz Sample Rate with Option R40, Center Frequency must be greater than or equal to 10

GHz

Preset

Mode Value

5G NR, LTEA FDD/TDD Automatically calculated

BASIC 125.0 kHz

BASIC 100 MHz

EDGEGSM 637.5 kHz

MSR 125.0 kHz

PNOISE 125.0 kHz

WCDMA 125.0 kHz

WLAN 31.25 MHz

Min/Max 12.5 Hz/Option dependent

For Option DP2, B40 or wider IF Bandwidth option:

Digital IF 10 MHz path 12.5 MHz

Digital IF 25 MHz path 31.25 MHz

Digital IF 40 MHz path 50 MHz

Option B85 85 MHz path 106.25 MHz

Option B1A 125 MHz path 156.25 MHz

Option B1X 140 MHz path 175 MHz

Option B1Y 160 MHz path 200 MHz
