3 Short-Range Comms & IoT Mode
3.9 Occupied BW Measurement
3.9.1.2 OBW Boundaries
Windows: "Graph" on page 1220, "Metrics - OBW Boundaries" on page 1223
The spectrum trace is displayed in the upper window. The lower window of OBW
Results view is replaced by the OBW boundaries table in this view. Occupied
bandwidth and X dB bandwidth for both lower and upper boundaries are displayed.
Example
:DISP:OBW:VIEW BOUN
3.9.1.3 Gate
See "Gate View On/Off" on page 2366
3.9.2 Windows
There are four available window types. The Gate window is available only when
"Gate View On/Off" on page 2366 is ON in the Gate Settings menu under Trigger.
View #
"Graph" on page 1220 1
"OBW Results" on page 1219 2
"OBW Boundaries" on page 1220 3
"Gate" on page 1224 4
3.9.2.1 Graph
Window #1
Appears in two Views, as follows:
View Size Position
"OBW Results" on page 1219 Three fifth, full width Top
"OBW Boundaries" on page 1220 Half, full width Top
Spectrum View
For SA, WCDMA, WLAN mode:
1220 Short Range Comms & IoT Mode User's &Programmer's Reference
