10 Hardware-Accelerated Fast Power Measurement (Remote Command Only)
10.2 Reset Fast Power Measurement (Remote Command Only)
Because two acquisitions, rather than a single acquisition, are made when spur suppression is enabled,
the measurement time will always be slower when spur suppression is enabled
Preset
False
Range
True
Enable spur suppression
False
Disable spur suppression
10.2.7 Electronic Attenuator Bypass
Example
:CALC:FPOW:POW1:DEF "ElecAttBypass =False"
Notes Lets you either utilize or bypass the electronic attenuator. The electronic attenuator is only available for
frequencies up to 3.6 GHz. Set to True when using frequencies above 3.6 GHz. Set to False when
using the preamp
Preset
True
Range
True
Bypass electronic attenuator
False
Use electronic attenuator
10.2.8 Electronic Attenuation
Example
:CALC:FPOW:POW1:DEF "ElecAttenuation=10"
Notes Option EA3 is required
The electronic attenuation value parameter sets the amount of electrical attenuation from 0 to 24 dB (1
dB steps)
Set ElecAttBypass = False to make sure the electronic attenuator path is enabled
Preset 0 dB
Range 0 – 24 dB (1 dB steps)
10.2.9 External Reference Frequency
Example
:CALC:FPOW:POW1:DEF "ExternalReferenceFrequency=10"
Notes This is the user-specified frequency of the external reference. Used when "Frequency Reference
Source" on page 2516 is set to ExternalFrequencyReference, or AutoEx-
ternalFrequencyReference when the external source is present. Unused if FrequencyRe-
ferenceSource is set to InternalFrequencyReference
Preset 10 MHz
Short Range Comms & IoT Mode User's &Programmer's Reference 2515
