Keysight x-series Instruction Manual

7 Save/Recall/Print
7.2 Recall
Format Extension
M9384B VXG 5GNR Setup
.sgen
PWSG Desktop Setup
.pwsg
89600 VSA 5GNR Setup
.setx
X-Series Measurement Application 5GNR Component Carrier Setup
.nrcc
Remote
Command
:MMEMory:LOAD:EVM:SETup ALL | CC0 | CC1 | CC2 | CC3 | CC4 | CC5 | CC6 | CC7
| CC8 | CC9 | CC10 | CC11 | CC12 | CC13 | CC14 | CC15,<string>
Example
:MMEM:LOAD:EVM:SET CC0,"mySetup.scp"
Status Bits/OPC
dependencies
Sequential - aborts the current measurement
7.2.37 Frame Index (.scp and .pwsg only)
Signal Studio (N7631C) and PWSG desktop may have configuration for multiple
frames. This parameter specifies which frame’s configuration will be recalled in
5GNR Modulation Analysis measurement from a .scp or .pwsg file.
Remote Command
:MMEMory:LOAD:EVM:FRAMe <int>
:MMEMory:LOAD:EVM:FRAMe?
Example
:MMEM:LOAD:EVM:FRAM 1
:MMEM:LOAD:EVM:FRAM?
Preset 0
State Saved No
Min 0
Max 100
7.2.38 Close VSA after recall (.setx only)
Automatically launches VSA (VSA 2021 or later version with valid license is required)
in the background, if it is needed to recall the specified .setx file. This provides
recalled settings to the 5GNR EVM measurement through an internal API. This
process will be slower and will consume more memory, because VSA is running in
the background.
Lets you specify whether VSA will be closed after recalling the current .setx file:
ON
Close VSA to improve performance and minimize memory usage
OFF
Keep VSA running to allow faster recall of additional .setx files
Remote Command
:MMEMory:LOAD:EVM:VSA:RELease 0 | 1 | OFF | ON
Short Range Comms & IoT Mode User's &Programmer's Reference 2247
