3 Short-Range Comms & IoT Mode
3.8 SEM Measurement
k is an index for each offset: k = 0 for offset A; k = 1 for offset B; k = 2 for offset C, etc.
The number of offsets is 12 (A-L).
# Item Unit
1
2k + 1, k = 0
Minimum margin from limit line on the negative offset A dB
2
2k + 2, k = 0
Minimum margin from limit line on the positive offset A dB
3
2k + 1, k = 1
Minimum margin from limit line on the negative offset B dB
4
2k + 2, k = 1
Minimum margin from limit line on the positive offset B dB
---
24
2k + 2, k = 11
Minimum margin from limit line on the positive offset L dB
3.8.9 Results for n = 18-20
n Return Value
18 Returns the displayed frequency domain spectrum trace data for Trace 2 separated by commas
19 Returns the displayed frequency domain spectrum trace data for Trace 3 separated by commas
20 Returns the displayed frequency domain absolute 2 limit trace data, separated by commas
3.8.10 Number of Offsets
The number of available offsets varies depending on the mode and option as below.
Mode Number of
available offsets
MSR LTEAFDD, LTEATDD, 5G NR 12 (Offset A to L)
WLAN 14 (Offset A to N)
Other Modes with option: N9060A-7FP, N9060B-2FP, N9060C-2FP,
N9060EM1D, N9060EM1E, or N90EMPSMB
12 (Offset A to L)
Other Modes without option N9060A-7FP, N9060B-2FP, N9060C-2FP,
N9060EM1D, N9060EM1E, or N90EMPSMB
6 (Offset A to F)
3.8.11 Views
All Modes provide three predefined views. In MSR, LTE-Advanced FDD/TDD and 5G
NR Modes, there is also a fourth predefined view. The views are listed in the table
Short Range Comms & IoT Mode User's &Programmer's Reference 1019
