8 Trigger
8.1 Trigger
–
External1 is not provided, you set the Sync Source back to RF Burst: the register
is cleared, message is also cleared. That’s because the instrument is
synchronized to RF Burst already. If you want to make a new synchronization,
you have to press “Reset Sync Monitor” you send SCPI command
“:TRIG:FRAM:SMON:RES”.
Remote Command
:TRIGger[:SEQuence]:FRAMe:SMONitor:RESet
Example
:TRIG:FRAM:SMON:RES
Notes This control works together with bit 1 “Waiting for Periodic Sync Source” in the :STATus:OPERa-
tion:INSTrument:CONDition status register
A “Periodic Trigger, Waiting for Sync Source” message will be generated after pressing this control,
and the status bit will be set
A “Periodic Trigger Synchronized” message will be generated after successfully synchronizing to Sync
Source, and the status bit will be cleared
Dependencies Only functional when Periodic Trigger is selected as the Trigger or Gate Source, and Sync Source is
not Off
Only available in VXT models M9410A/11A/15A/16A
Status Bits/OPC
dependencies
Bit 6 of :STATus:OPERation:CONDition will be set after pressing this control
8.1.21 Trigger Optimization
Sets the trigger behavior for various desired operation conditions.
Remote Command
:TRIGger[:SEQuence]:OPTimize:MODE NORMal | MJITter
For option details, see "Options" on page 2360
:TRIGger[:SEQuence]:OPTimize:MODE?
Example Select trigger optimization for minimum jitter:
:TRIG:OPT:MOD MJIT
Dependencies Only appears in VXT models M9410A/11A/15A/16A
Minimum jitter is functional only when digital IF BW is lower than 300MHz. When Trigger
Optimization is set to MJITter and it is not in effect, the following warning message appears in the
status bar:
Settings Alert; Minimum Jitter is not available
Preset
NORMal
State Saved Yes
Range
NORMal|MJITter
Options
Trigger optimization options are:
Short Range Comms & IoT Mode User's &Programmer's Reference 2360
