Keysight x-series Instruction Manual

3 Short-Range Comms & IoT Mode
3.8 SEM Measurement
Option SCPI Behavior
Gaussian
GAUSsian
The selected filter is applied to carriers and all offsets
Flattop
FLATtop
Auto Sense
ASENse
The filter type is automatically selected for each carrier and
offset in a way such that measurement speed and accuracy are
optimized
Filter Auto Sense Rules:
–
Flattop is selected when "Enable Wideband IF for FFT" on
page 1184 is ON
–
Flattop is selected for offsets close to the reference carrier
–
For all other cases, Gaussian is selected
Remote
Command
[:SENSe]:SEMask:BANDwidth:SHAPe ASENse | GAUSsian | FLATtop
[:SENSe]:SEMask:BANDwidth:SHAPe?
Example
:SEM:BAND:SHAP GAUS
:SEM:BAND:SHAP?
Preset
ASENse
State Saved Saved in instrument state
Range Auto Sense (each offset and carrier) | Gaussian (all offsets and carriers) | Flattop (all offsets and carriers)
3.8.15 Display
Lets you configure display items for the current Mode, Measurement View or
Window.
3.8.15.1 Meas Display
Contains controls for setting up the display for the current Measurement, View or
Window.
Limit Lines
Toggles Limit Lines display for this measurement On or Off.
Remote Command
:CALCulate:SEMask:LLINe:STATe ON | OFF | 1 | 0
:CALCulate:SEMask:LLINe:STATe?
Example
:CALC:SEM:LLIN:STAT OFF
:CALC:SEM:LLIN:STAT?
Short Range Comms & IoT Mode User's &Programmer's Reference 1079
