6 Input/Output
6.7 Output
Dependencies Only appears if Screen Video is the selected Analog Output
Preset Unaffected by Preset, but set to NORM by Restore Input/Output Defaults or Restore System Defaults-
>All
State Saved Saved in Input/Output State
6.7.3 Digital Bus Out
Turns on the LVDS Digital Output port for outputting digital acquisition data.
–
When ON, all acquisitions are streamed to the output port including acquisitions
for internal purposes such as Alignment. The internal processing and routing of
acquisitions continues as usual and is unaffected by the state of Bus Out
–
When OFF, no signal appears on the LVDS port
Remote Command
:OUTPut:DBUS[1][:STATe] ON | OFF | 1 | 0
:OUTPut:DBUS[1][:STATe]?
Example
:OUTP:DBUS ON
Dependencies Requires option RTL or control is not displayed
Digital Bus Out and Wideband Digital Bus cannot both be ON at the same time, so:
–
When Wideband Digital Bus is turned ON, if Digital Bus Out is already ON, an advisory message is
displayed, “Wideband Digital Bus On, Digital Bus (narrow band) forced to Off”
–
When Digital Bus Out is turned ON, if Wideband Digital Bus is already ON, an advisory message is
displayed, “Digital Bus (narrow band) On, Wideband Digital Bus forced to Off”
Preset
OFF
Set by Restore Input/Output Defaults
State Saved Saved in Input/Output State
6.7.4 Wideband Digital Bus
Turns on the LVDS port on the Wideband IF, which causes the I/Q pairs from the
current measurement to be sent to this port.
NOTE
This control is grayed-out in all Modes except RTSA, which offers the only
measurement that supports wideband streaming.
–
When ON, the internal processing and routing of acquisitions continues as usual,
and the display of measurement data is unaffected
–
When OFF, no signal appears on the LVDS port
2159 Short Range Comms & IoT Mode User's &Programmer's Reference
