6 Input/Output
6.1 RF Source
UID
Unique ID
LICSTS
License Status
Range
"DESC:", "SR:", "RTS:", "RMS:", "M1P:", "M2P:", "M3P:", "M4P:", "ALCHR:",
"RFBR:", "FOFF:", "AWGNST:", "AWGNCN:", "AWGNCBW:", "AWGNNBW:", "AWGNCRMS:",
"ORP:", "UID:", "LICSTS"
6.1.12 Trigger Initiate
Initiates an immediate trigger event if the trigger source (under ARB Setup) is set to
KEY.
Dependencies Grayed-out unless Trigger Source is set to KEY and an ARB waveform is configured
6.1.13 Source Sync
Accesses a menu for setting up Source Synchronization for multiple models.
Only appears in modular products such as VXT, and only when the instrument is
configured for MIMO analysis.
6.1.13.1 Sync Config
Lets you config MIMO type for source.
Grayed-out when Primary and Secondary modules are in Sync State.
Remote Command
:SOURce:SYNC:CONFig NONE | TWO | THRee | FOUR | SIX | EIGHt | DONE | DTWO |
DTHR | DFOU
See "Option Details" on page 2019
:SOURce:SYNC:CONFig?
Example
:SOUR:SYNC:CONF TWO
Dependencies
EXM 2x2 and 1x1+1x1 MIMO are supported when license E6640A-M22 is
enabled
2x2 and 3x3 MIMO are supported when license E6640A-M33 is enabled
2x2, 3x3, 4x4 and 2x2+2x2 MIMO are supported when license E6640A-
M44 is enabled
VXT models
M9410A/11A
No-Across chassis MIMO is supported when license M941xA-MMO is
enabled
Across chassis MIMO is supported when license M941xA-MTS is
enabled
Short Range Comms & IoT Mode User's &Programmer's Reference 2018
