3 Short-Range Comms & IoT Mode
3.11 IQ Waveform Measurement
View
See "Views" on page 1511.
User View
Lets you choose a View from the saved User Views for the current measurement.
This panel only appears if a User View exists for the current measurement.
Remote
Command
:DISPlay:VIEW:ADVanced:SELect <alphanumeric>
:DISPlay:VIEW:ADVanced:SELect?
Example Select Baseband as the current View
:DISP:VIEW:ADV:SEL “Baseband”
Notes You must be in the measurement whose View you are trying to set to send the command. You can only
set Views for the current measurement using this command
For predefined views, the parameter is derived from the view name that is shown in the View list in the
user interface. For example, if you are trying to select the Trace Zoom view in the Swept SA
measurement, you send:
:DISP:VIEW:ADV:SEL "Trace Zoom"
because “Trace Zoom” is the name of the View as seen in the Mode/Meas dialog or in the Display, View
menu
You cannot use the legacy View parameter (which in this case would be TZOom) with
:DISP:VIEW:ADV:SEL
<alphanumeric> is case insensitive; you can specify mixed case, however the name will be
evaluated on a single case. Thus, both of the following forms work:
:DISP:VIEW:ADV:SEL "Trace Zoom"
:DISP:VIEW:ADV:SEL "TRACE ZOOM"
If the specified view is not a valid View, the query returns the error message “-224, Illegal parameter
value; View with the name <alphanumeric> does not exist”
If the display is disabled (via :DISP:ENAB OFF) then the error message “-221, Settings conflict;
View SCPI cannot be used while Display is disabled” is generated
Backwards
Compatibility
SCPI
The legacy node
:DISPlay:VIEW[:SELect]
is retained for backwards compatibility, but it only supports predefined views
Restore Layout to Default
Restores the Layout to the default for Basic.
Modified Views are very temporary; if you exit the current measurement they are
discarded, and they are not saved in State. To retain this View for later use, and to
Short Range Comms & IoT Mode User's &Programmer's Reference 1567
