Keysight x-series Instruction Manual

3 Short-Range Comms & IoT Mode
3.7 ACP Measurement
Cont, a new trace is taken. If any trace is in average or hold, the averaging starts
over.
Because of sweep time quantization issues, the knob and up/down keys cannot be
used to adjust the number of points.
When in a split screen display each window may have its own value for points.
When sweep points is changed, an informational message "Sweep points changed,
all traces cleared" is displayed and in 5G NR Mode, Auto Sweep Points is set to OFF
(0).
Remote Command
[:SENSe]:ACPower:SWEep:POINts <integer>
[:SENSe]:ACPower:SWEep:POINts?
Example
:ACP:SWE:POIN 500
:ACP:SWE:POIN?
Dependencies Not available when Signal ID is On in External Mixing
Neither the knob nor the step keys can be used to change this value. If it is tried, a warning is given
Not displayed in Modes that do not support Swept
This parameter is automatically calculated and not configurable when Meas Method is set to Fast
Power
Couplings Whenever the number of sweep points change:
–
All trace data is erased
–
Any traces with Update Off will also go to Display OffSweep time is re-quantized
–
Any limit lines that are on will be updated
–
If averaging/hold is on, averaging/hold starts over
–
Auto Sweep Points is set to OFF (5G NR Mode only)
The resolution of setting the sweep time depends on the number of points selected
Preset
5G NR Mode, in all models except M9410A/11A/15A 5001
All others 1001
State Saved Saved in instrument state
Min 1
Max 20001
Annotation On second line of annotations, in lower right corner in parenthesis behind the sweep annotation
3.7.14.3 X Scale
Accesses controls that enable you to set the horizontal scale parameters.
986 Short Range Comms & IoT Mode User's &Programmer's Reference
