3 Short-Range Comms & IoT Mode
3.4 HRP UWB Demodulation Measurement
n Return Value
ERDEV-BPRF.
For item 15 (SECDED Status), possible values and corresponding error types are:
value 0 1 2 3
SECDED Status Unknown Ok Single Error Double Error
For item 14 (SECDED Err Loc), the number specifies the error location of SECDED, and is valid only when
SECDED Status is Single Error. Possible values and corresponding error locations are:
value -999 -1 <13
SECDED Err Loc Invalid ParityBits Bits+loc Value
8 Returns the Impulse Response trace data as a list of x,y pairs.
The x-axis values are in units of Second. The y-values are in units of dB.
9 Returns the Impulse Response upper limit trace data as a list of x,y pairs.
The x-axis values are in units of Second. The y-values are unified.
10 Returns the Impulse Response lower limit trace data as a list of x,y pairs.
The x-axis values are in units of Second. The y-values are unified.
11 Returns the Transmit Mask limit data in units of dB.
12 Returns the Error Vector Time trace data in percentage.
13 Returns MMS results:
# Result Unit, if any
1 Rsf Avg Power dBm
2 Rsf Peak Power dBm
3 Rif Avg Power dBm
4 Rif Peak Power dBm
5 Rsf RMARKER dBm
14 Returns Rif table
# Result Unit, if any
1 Column Number
3 for current version
2 Rif index 0-7
3 Rif RmarkerFirst ms
4 Rif RmarkerLast ms
Results 2 to 4 repeat for each Rif
3.4.1 Views
This measurement has the following predefined Views:
Short Range Comms & IoT Mode User's &Programmer's Reference 435
