Keysight x-series Instruction Manual

3 Short-Range Comms & IoT Mode
3.7 ACP Measurement
Notes The graticule is the set of horizontal and vertical lines that make up the grid/divisions for the X-Axis and
Y-Axis
Preset
ON
State Saved Saved in instrument state
Backwards
Compatibility
SCPI
:DISPlay:WINDow[1]:TRACe:GRATicule:GRID[:STATe] OFF | ON | 0 | 1
:DISPlay:WINDow[1]:TRACe:GRATicule:GRID[:STATe]?
This command is accepted for backwards compatibility with older instruments, but the WINDow,
TRACe and GRID parameters are ignored
Screen Annotation
Controls the display of the annunciation and annotation around the graticule,
including any annotation on lines (such as the display line, the threshold line, etc.)
and the Y-Axis annotation, for all windows with screen annotation in all
measurements in the current Mode.
This does not include marker annotation (or the NdB result). When OFF, the
graticule expands to fill the entire graticule area, leaving only the 1.5% gap above
the graticule, as described in the Trace section.
Remote Command
:DISPlay:ANNotation:SCReen[:STATe] OFF | ON | 0 | 1
:DISPlay:ANNotation:SCReen[:STATe]?
Example
:DISP:ANN:SCR OFF
Dependencies Grayed-out and forced to OFF when System Display Settings, Annotation is OFF
Preset
ON
This remains OFF through a Preset when System Display Settings, Annotation is set to OFF
State Saved Saved in instrument state
Trace Annotation
Turns on and off the labels on the traces, showing their detector (or their Math
Mode) as described in the Trace section, for all windows in all measurements in the
current Mode for which Trace Annotation on/off is supported.
If Trace Math is being performed on a trace, then the Trace Math annotation
replaces the detector annotation.
For measurements that support limit lines, this key also turns on and off the labels
on the Limit Lines. The label is the Limit number annotation and Limit Comment
displayed on the graph. If the length of the comment is greater than 20 characters,
the first 8 characters and the last 8 characters are displayed, joined with ….
Remote Command
:DISPlay:ANNotation:TRACe[:STATe] ON | OFF | 1 | 0
Short Range Comms & IoT Mode User's &Programmer's Reference 837
