6 Input/Output
6.8 Trigger Output
Example
:TRIGger:PXIE:SOURce:OUTPut:LINE 0
Dependencies Only appears in EXM, VXT and M941xE
Preset 4
State Saved Saved in instrument state
Range [0,7]
6.8.7 Analyzer PXI Trig Out
Selects the signal that will be output from Analyzer PXI Trigger Line (Backplane
Trigger Line 0~3).
Remote Command
:TRIGger:PXIE:ANALyzer[:SEQuence]:OUTPut HSWP | MEASuring | MAIN | GATE |
GTRigger | OEVen | OFF
See "Option Details" on page 2174
:TRIGger:PXIE:ANALyzer[:SEQuence]:OUTPut?
Example
:TRIG:PXIE:ANAL:OUTP HSWP
Dependencies Only available on certain modular analyzers, such as CXA-m, VXT models M9410A/11A/15A/16A and
M9410E/11E/15E/16E
For VXT models M9410A/11A/15A/16A, only OFF, MEASuring and MAIN are available
Preset Unaffected by Preset but is preset to OFF by Restore Input/Output Defaults or Restore System
Defaults->All
State Saved Saved in instrument state
Option Details
Here are details of all Analyzer PXI Trigger Output options:
Source SCPI Notes
Off
OFF
Selects no signal to be output to the Analyzer PXI backplane trigger line
Sweeping
(HSWP)
HSWP
Selects the Sweeping Trigger signal to be output to the Analyzer PXI backplane trigger line
when a measurement is made. This signal has historically been known as "HSWP" (High =
Sweeping), and is 5 V TTL level with 50-ohm output impedance
Measuring
MEAS
Selects the Measuring trigger signal to be output to the Analyzer PXI backplane trigger
line. This signal is true while the Measuring status bit is true
Main Trigger
MAIN
Selects the current instrument trigger signal to be output to the Analyzer PXI backplane
trigger line
Gate Trigger
GTR
Selects the gate trigger signal to be output to the Analyzer PXI backplane trigger line. This
is the source of the gate timing, not the actual gate signal
Gate
GATE
Selects the gate signal to be output to the Analyzer PXI backplane trigger line. The gate
signal has been delayed and its length determined by delay and length settings. When the
Short Range Comms & IoT Mode User's &Programmer's Reference 2174
