3 Short-Range Comms & IoT Mode
3.12 Monitor Spectrum Measurement
Preset 1001 unless noted below
2001: 5GNR
State Saved Saved in instrument state
Min 1
Max 20001
Annotation On second line of annotations, in lower right corner in parenthesis behind the sweep annotation
3.12.10 Trace
Lets you control the acquisition, display, storage, detection, and manipulation of
trace data for the available traces.
The "Trace Control" on page 1730 tab in this menu contains radio-button selections
for the trace type (Clear/Write, Trace Average, Max Hold, Min Hold) and View/Blank
setting for the selected trace.
3.12.10.1 Select Trace
Specifies the selected trace, which is the trace that will be affected when you
change trace settings.
Select Trace appears above the menu panel, indicating that it applies to all controls
in the menu panel. Select Trace is blanked if you select a tab whose controls do not
depend on the selected trace (for example, Trace Function).
Notes The selected trace is remembered even when not in the Trace menu
Dependencies For the Swept SA measurement:
–
In Image Suppress mode, when you select a trace it becomes the active trace, and the formerly
active trace goes into View
–
When you turn on Image Suppress, Update turns off for all traces except the selected trace
For the ACP measurement, when Meas Method is RBW, FAST or FPOWer, Select Trace is disabled
Preset Trace 1
State Saved Yes
3.12.10.2 Trace Control
The controls on this tab allow you to set the "Trace Type" on page 1731 and its
update mode.
There are four Trace Types:
1730 Short Range Comms & IoT Mode User's &Programmer's Reference
