Keysight x-series Instruction Manual

3 Short-Range Comms & IoT Mode
3.7 ACP Measurement
If there is only one carrier present, Ref Carrier Freq is the same as Center Frequency
Preset Calculated based on the current Center Frequency
State Saved Saved in instrument state
Min/Max -79.999995 MHz/Hardware Dependent
Backwards
Compatibility SCPI
[:SENSe]:MCPower:RCFRequency[1]|2 (Power Suite)
Auto Function
Remote
Command
[:SENSe]:ACPower:CARRier[1]|2:RCFRequency:AUTO OFF | ON | 0 | 1
[:SENSe]:ACPower:CARRier[1]|2:RCFRequency:AUTO?
Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink
Example
:ACP:CARR:RCFR:AUTO OFF
:ACP:CARR:RCFR:AUTO?
Preset
ON
State Saved Yes
Range Auto | Man
Backwards
Compatibility
SCPI
[:SENSe]:MCPower:RCFRequency[1]|2:AUTO
Measurement Type
Changes the reference used for the measurement. This allows you to make absolute
and relative power measurements of either total power or the power normalized to
the measurement bandwidth.
–
Total Pwr Ref (TPRef) sets the reference to the total carrier power
–
PSD Ref (PSDRef) sets the reference to the power spectral density of the carrier
Remote Command
[:SENSe]:ACPower:TYPE TPRef | PSDRef
[:SENSe]:ACPower:TYPE?
Example
:ACP:TYPE PSDR
:ACP:TYPE?
Preset
TPRef
State Saved Saved in instrument state
Range Total Power Ref | PSD Ref
Short Range Comms & IoT Mode User's &Programmer's Reference 947
