Keysight x-series Instruction Manual

3 Short-Range Comms & IoT Mode
3.8 SEM Measurement
Radio Std Presets
802.11 ac/ax/be
(20MHz/40MHz/80MHz/160MHz)
802.11 be (320MHz)
802.11ah
(1MHz/2MHz/4MHz/8MHz/16MHz)
802.11af (6MHz/7MHz/8MHz)
802.11 ac/ax (80+80 MHz)
ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON,
ON, ON, ON
802.11b/g (DSSS/CCK/PBCC)
ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON,
ON, ON, ON
802.11j/p 20M, j/p 10M, p5M
OFF, OFF, OFF, ON, ON, ON, ON, ON, ON, ON,
ON, ON, ON, ON
Rel Start
Sets a relative power level limit at the start frequency for the selected offset. The
relative power level limit ranges from –200 to +50 dBc.
The fail condition is set remotely by [:SENSe]:SEMask:OFFSet[n]
[:OUTer]:LIST:TEST for each offset channel test.
You can turn off (not use) specific offset channels remotely with
[:SENSe]:SEMask:OFFSet[n][:OUTer]:LIST:STATe.
The query returns values currently set to the relative power test limits.
When sending the remote command, missing values are not permitted; that is, if you
want to change values 2 and 6, you must send all values up to 6. Subsequent values
remain unchanged. The query returns 14 values for WLAN Mode, or12 values for
other Modes.
Remote
Command
[:SENSe]:SEMask:OFFSet[1]|2[:OUTer]:LIST:STARt:RCARrier <rel_ampl>, …
[:SENSe]:SEMask:OFFSet[1]|2[:OUTer]:LIST:STARt:RCARrier?
Example
:SEM:OFFS:LIST:STAR:RCAR -30, -30, -30, -30, -30, -30
:SEM:OFFS:LIST:STAR:RCAR?
Notes Comma-separated list of values
OFFSet 1 is for BTS, 2 for MS. Default is BTS
Note that Offset sub op code 2 is supported only in Modes other than SA. In SA mode, Offset sub op
code 1 is used for both BTS and MS
Preset When the max number of offsets is 6:
Short Range Comms & IoT Mode User's &Programmer's Reference 1129
