Keysight x-series Instruction Manual

3 Short-Range Comms & IoT Mode
3.12 Monitor Spectrum Measurement
Average Mode
Toggles the Average Mode:
–
EXPonential- continues measurement averaging, using the specified number
of averages to compute each averaged value. The average is displayed at the
end of each sweep
–
REPeat- causes the measurement to reset the average counter each time the
specified number of averages is reached
Remote
Command
[:SENSe]:MONitor:AVERage:TCONtrol EXPonential | REPeat
[:SENSe]:MONitor:AVERage:TCONtrol?
Example
:MON:AVER:TCON EXP
:MON:AVER:TCON?
Preset
EXPonential
State Saved Yes
Range
EXPonential|REPeat
Spur Avoidance
Because the VXT models M9410A/11A/15A are direct-conversion (zero-IF)
receivers, feedthrough leakage from the local oscillator appears as a spurious signal
(spur) at the center frequency. The Spur Avoidance function is provided to eliminate
this spur, at the expense of some measurement speed. For Spur Avoidance, the
instrument uses a software algorithm to remove this spur from the displayed
measurement data.
Some measurements allow you to turn off Spur Avoidance, but in this measurement
it is always enabled. Therefore, in this measurement the Spur Avoidance switch is
unavailable (grayed out) and set to Enabled.
Furthermore, if you press the grayed-out switch, this popup message appears:
Always enabled in this measurement. See manual for details
Remote Command
[:SENSe]:MONitor:SAVoid[:STATe]?
Example
:MON:SAV?
Always returns ON
Dependencies This control only appears in VXT models M9410A/11A/15A
Preset
ON
State Saved Saved in instrument state
Range
ON
1708 Short Range Comms & IoT Mode User's &Programmer's Reference
