3 Short-Range Comms & IoT Mode
3.3 LoRa (CSS) Demodulation Measurement
scaled logarithmically. This affects the unit of the Y axis annotation, the reference
value annotation and the readout of Marker Y.
Scale Type is Log Scale Type is Lin
dBHz Hz
Remote
Command
:DISPlay:LORA:WINDow3:TRACe:Y[:SCALe]:SPACing LINear | LOGarithmic
:DISPlay:LORA:WINDow3:TRACe:Y[:SCALe]:SPACing?
Example
:DISP:LORA:WIND3:TRAC:Y:SPAC LOG
:DISP:LORA:WIND3:TRAC:Y:SPAC?
Notes Changing the Scale Type value always changes the Y Axis Unit (:UNIT:LORA:AFSPectrum)
Preset
LINear
State Saved Saved in instrument state
3.3.3.2 Attenuation
Controls the attenuator functions and interactions between the attenuation system
components.
There are two attenuator configurations in the X-Series. One is a Dual-Attenuator
configuration consisting of a mechanical attenuator and an optional electronic
attenuator. The other configuration uses a single attenuator with combined
mechanical and electronic sections that controls all the attenuation functions.
Different models in the X-Series come with different configurations.
–
See "Dual-Attenuator Configurations" on page 330
–
See "Single-Attenuator Configuration" on page 330
Most attenuation settings are the same for all measurements – they do not change
as you change measurements. Settings like these are called “Meas Global” and are
unaffected by Meas Preset.
Only available when the hardware set includes an input attenuator, which is
typically only the case for Keysight’s benchtop instruments. For example, this tab
does not appear in VXT models M9420A/10A/11A/15A/16A,
M9410E/11E/15E/16E, nor in UXM. In UXM, all Attenuation and Range settings are
disabled, as the expected input power level is handled by the Call Processing App
that drives the DUT power control.
Dependencies In measurements that support the I/Q inputs, unavailable when I/Q is the selected input. Replaced by
the Range tab in that case
Short Range Comms & IoT Mode User's &Programmer's Reference 329
