Keysight x-series Instruction Manual

6 Input/Output
6.9 Calibration
State Saved Saved in instrument state
Min If Scale Type is Lin, the min Stop Frequency is changed to -79.999990MHz
Max Depends on the instrument maximum frequency
6.9.1.29 Freq Step
Specifies the step frequency of the selected Cal. This determines the points between
the start and stop frequencies to use for Calibration.
Remote Command
:SYSTem:CALibration:ROW[1]|2|…|100:FREQuency:STEP <freq>
:SYSTem:CALibration:ROW[1]|2|…|100:FREQuency:STEP?
Example
:SYST:CAL:ROW2:FREQ:STEP 1e9
Notes Max values depend on Hardware Options
Dependencies The SCPI command applies to the currently selected Cal Group
If the subopcode does not reference an existing Cal row in the Cal Group, the error message “-221,
Settings conflict; Subopcode does not reference an existing Cal row” is generated
You cannot set Freq Step > Stop frequency - Start frequency
Attempts to set Freq Step > Stop frequency - Start frequency results in Freq Step being set to Stop
frequency - Start frequency
Couplings Coupled to "Freq Points" on page 2193. Changing Freq Step adjusts Freq Points using (((Stop Freq –
Start Freq) / Freq Step) + 1) and clips to the next integer value, which may result in Freq Step being
clipped too
If Freq Step is set to a value > Stop Freq – Start Freq Stop Freq is increased, and Freq Points is set to
1
Preset All 10 kHz
State Saved Saved in instrument state
Min 1 Hz
Max Depends on the instrument maximum frequency
6.9.1.30 Freq Points
Specifies the frequency points of the selected Cal. This determines the points
between the start and stop frequencies to use for Calibration.
Remote
Command
:SYSTem:CALibration:ROW[1]|2|…|100:FREQuency:POINts
:SYSTem:CALibration:ROW[1]|2|…|100:FREQuency:POINts?
Example
:SYST:CAL:ROW2:FREQ:POIN 100
Couplings Coupled to "Freq Step" on page 2193. Changing Freq Points adjusts Freq Step using (Stop Freq – Start
Freq) / (Freq Points – 1) and clips to the next integer value, which may result in Freq Step being clipped
2193 Short Range Comms & IoT Mode User's &Programmer's Reference
