6 Input/Output
6.9 Calibration
B4G
4 GHz
EXT
Depends on the hardware
In cases where the path is not available but is selected via SCPI, generates error -241,”Hardware
missing; Option not installed”
Dependencies
Path Availability requires Installation of:
25 MHz 25 MHz or wider IF Bandwidth option
40 MHz 40 MHz or wider IF Bandwidth option
85 MHz 85 MHz or wider IF Bandwidth option
125 MHz 125 MHz or wider IF Bandwidth option
140 MHz Option B1X
160 MHz Option B1Y. B1Y cannot be installed without B1X
255 MHz Option B2X or wider IF Bandwidth option
510 MHz Option B5Y or wider IF Bandwidth option
1 GHz Option H1G/B1G or wider IF Bandwidth option
2 GHz Option B2G(R20) or wider IF Bandwidth option
4 GHz Option B4G(R40) or wider IF Bandwidth option
1.5 GHz Option R15
If Option B85 and either Option B1A or Option B1X are installed, the 85MHz option does not appear,
and B85M is disabled. Sending the command to select B85M in this case generates an error -221,
“Settings Conflict; Use wider bandwidth selection”
If Option B1A and Option B1X are both installed, the 125MHz option does not appear, and B125M is
disabled. Sending the command to select B125M in this case generates an error -221, “Settings
Conflict; Use wider bandwidth selection”
In cases where the path is not available, but is selected via SCPI, error -241,”Hardware missing;
Option not installed” is generated
The preset value depends on the Digital IF BW setting of the default measurement
Preset If the 25MHz path is not available, presets to 10MHz
State Saved No
Range
B10M | B25M | B40M | B85M | B125M | B140M | B160M | B255M | B510M | B1G |
B1500M | B2G | B4G | EXT
6.9.1.47 IF Gain
Determines the IF Gain to be used in the Calibration
Remote Command
:SYSTem:CALibration:ROW[1]|2|…|100:IF:GAIN[:STATe]AUTO|HIGH|LOW|ALL
:SYSTem:CALibration:ROW[1]|2|…|100:IF:GAIN[:STATe]?
2203 Short Range Comms & IoT Mode User's &Programmer's Reference

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
