6 Input/Output
6.2 Input
Remote Command
[:SENSe]:HDUPlex:PORT:INPut RFIO3 | RFIO4
Example
:HDUPlex:PORT:INPut RFIO3
:HDUPlex:PORT:INPut?
Dependencies Only appears in EXM
If RFIO3 is selected as “Half Duplex Output Port”, then “Half Duplex Input Port” will be set to RFIO4
automatically. If RFIO4 is selected as “Half Duplex Output Port”, then “Half Duplex Input Port” will be
set to RFIO3 automatically
Preset
RFIO3
State Saved Saved in State
6.2.6 Port Information (Remote Command Only)
Provides information about an instrument port. The return information consists of
two comma-separated fields:
–
Field 1: the connection status (0 or 1)
–
Field 2: a string of port information
The return information is device-dependent.
Remote Command
[:SENSe]:FEED[:RF]:PORT:INFormation? RFIN | RFIN2 | RFFD | RFHD | A1 | A2 |
A3 | B1 | B2 | B3 | IFIO1 | IFIO2 | ANT | TR
Example
:FEED:PORT:INF? A1
example = 1,”US56160060” where 1 is the connection status and ”US56160060” is the port
information
Notes For E7760B:
The connection status (first field in the return value) indicates:
0 – the port is either not licensed for use or is not connected to a mmWave Transceiver
1 – the port is licensed; and for the case of mmWave ports, the port is connected to a mmWave
Transceiver
The port information (second field in the return value) contains:
“” (empty string) – no applicable information
Serial Number – the serial number of the connected mmWave Transceiver
If you send an incompatible parameter, the return values are: 0,””
Dependencies Only valid for E7760B
6.2.7 RF Preselector
In models that support the RF Preselector, such as PXE (N9048B), allows you to turn
the preselector on or off.
2047 Short Range Comms & IoT Mode User's &Programmer's Reference
