Keysight x-series Instruction Manual

6 Input/Output
6.5 Corrections
6.5.2 Correction On/Off
Turning the Selected Correction from OFF to ON allows the values in it to be applied
to the data. This state transition also automatically turns on "Apply Corrections"
(sets it to ON), otherwise the correction would not take effect.
A new sweep is initiated if an amplitude correction is switched on or off. Note that
changing, sending or loading corrections data does not directly initiate a sweep,
however in general these operations will turn corrections on, which does initiate a
sweep.
Remote Command
[:SENSe]:CORRection:CSET[1]|2|…|16[:STATe] ON | OFF | 1 | 0
[:SENSe]:CORRection:CSET[1]|2|…|16[:STATe]?
Example
:SENS:CORR:CSET1 ON
Dependencies Changing this from OFF to ON automatically turns on "Apply Corrections"
Note that if any Correction is turned on that has a transducer unit set (other than “None”), the Y-Axis
Unit of the instrument is forced to that Transducer Unit. All other Y-Axis Unit choices are grayed-out
This command generates an “Option not available” error unless you have the proper option installed in
your instrument
Preset Not affected by Preset. Set to OFF by Restore Input/Output Defaults
State Saved Saved in instrument state
Annotation If any Correction is turned on, Corr in the Meas Bar displays in amber to indicate Corrections are in
use
Backwards
Compatibility
Notes
Unlike legacy instruments, Preset does not turn Corrections off (Restore Input/Output Defaults does)
6.5.3 Correction Port
Maps one of the sets of corrections to a particular I/O port. This control allows any
Input port (including External Mixing, BBIQ, the RF2 input, etc.) to be mapped to a
specific Correction, so that the Correction is only applied when that Port is being
used by the current Screen. You can also map any internal source Output port to a
specific Correction.
When Current Input (CINPut) is selected for Correction Port, it chooses the current
input port of the current Screen for the selected Correction. In other words, the
Correction applies to whichever input is selected. If the input changes, the
correction applies to the new input.
When using the VXT M9410A/11A with Remote Radio Heads (such as the Keysight
M1740A mmWave Transceiver for 5G), the choices in the dropdown menu appear as
:
2115 Short Range Comms & IoT Mode User's &Programmer's Reference
