Keysight x-series Instruction Manual

3 Short-Range Comms & IoT Mode
3.11 IQ Waveform Measurement
trigger period is set to the current Meas Time value. Any changes to Meas Time
change the Periodic trigger period to the same value and vice versa. If a trigger
source other than Periodic trigger is manually selected, the Time Avg Num
Auto/Man toggle is set to Man.
Remote
Command
[:SENSe]:WAVeform:AVERage:TACount <integer>
[:SENSe]:WAVeform:AVERage:TACount?
Example
:WAV:AVER:TAC 10
:WAV:AVER:TAC?
Notes Only available when Option DP2, B40, or wider IF Bandwidth option is installed
Preset 1
State Saved Saved in instrument state
Min/Max 1/65535
Auto Function
Remote
Command
[:SENSe]:WAVeform:AVERage:TACount:AUTO OFF | ON | 0 | 1
[:SENSe]:WAVeform:AVERage:TACount:AUTO?
Example
:WAV:AVER:TAC:AUTO ON
:WAV:AVER:TAC:AUTO?
Preset
ON
Range
Auto|Man
Meas Time
Lets you set how long the measurement is performed. X Scale only changes the
scale of the display.
Remote
Command
[:SENSe]:WAVeform:SWEep:TIME <time>
[:SENSe]:WAVeform:SWEep:TIME?
Example
:WAV:SWE:TIME 50 ms
:WAV:SWE:TIME?
Notes Specifies and returns how long the measurement is performed. It is the time record length of the
measurement waveform. The Max time may be reduced when the sample frequency is high due to the
memory limitation
Preset LTE, LTETDD, LTEAFDD, LTEATDD, 5G NR Modes: 10 ms
All other Modes: 2.000000 ms
State Saved Saved in instrument state
Range 1.000 us to 100.00 s
Short Range Comms & IoT Mode User's &Programmer's Reference 1595

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
