3 Short-Range Comms & IoT Mode
3.4 HRP UWB Demodulation Measurement
Example
:HUWB:BAND 8 MHz
:HUWB:BAND?
Preset 750 MHz
State Saved Saved in instrument state
Min/Max 1 kHz / Max Info BW
Max Info BW depends on Data Source and Input Type:
Data Source Type Option Value
Input RF None 10 MHz
WB (25 MHz or wider) Hardware Option Limit
I/Q (for I+jQ) None 20 MHz
B25 50 MHz
File 100 GHz
3.4.5 Display
Opens the Display menu, which enables you to configure display items for the
current Mode, Measurement, View or Window.
3.4.5.1 View
Contains controls for selecting the current View, and for editing User Views.
View
See "Views" on page 435.
User View
Lets you choose a View from the saved User Views for the current measurement.
This panel only appears if a User View exists for the current measurement.
Remote
Command
:DISPlay:VIEW:ADVanced:SELect
<alphanumeric>
:DISPlay:VIEW:ADVanced:SELect?
Example Select Baseband as the current View
:DISP:VIEW:ADV:SEL “Baseband”
Notes You must be in the measurement whose View you are trying to set to send the command. You can only
set Views for the current measurement using this command
For predefined views, the parameter is derived from the view name that is shown in the View list in the
Short Range Comms & IoT Mode User's &Programmer's Reference 479
