Keysight x-series Instruction Manual

3 Short-Range Comms & IoT Mode
3.3 LoRa (CSS) Demodulation Measurement
Command
[:SENSe]:LORA:AFSPectrum:FREQuency:STARt?
Example
:LORA:AFSP:FREQ:STAR 10 Hz
:LORA:AFSP:FREQ:STAR?
Couplings If the start frequency is set to a value less than the value of the stop frequency minus 10 Hz, the stop
frequency will not change during the adjustment of the start frequency. Otherwise, the stop frequency
will be coupled to the value of the start frequency plus 10 Hz
Preset 0 Hz
State Saved Saved in instrument state
Min 0 Hz
Max 99.999990 MHz
Annotation AF Start Freq <value> appears in the lower left corner of the AF Spectrum window
Status Bits/OPC
dependencies
Non-overlapped
AF Stop Freq
Sets the value of the rightmost position of the abscissa on the AF spectrum window.
Remote
Command
[:SENSe]:LORA:AFSPectrum:FREQuency:STOP <freq>
[:SENSe]:LORA:AFSPectrum:FREQuency:STOP?
Example
:LORA:AFSP:FREQ:STOP 20 kHz
:LORA:AFSP:FREQ:STOP?
Couplings If the stop frequency is set to a value greater than the value of the start frequency plus 10 Hz, the start
frequency will not change during the adjustment of the stop frequency. Otherwise, the start frequency
will be coupled to the value of the stop frequency minus 10 Hz
Preset 20 kHz
State Saved Saved in instrument state
Min 10 Hz
Max 100 MHz
Annotation AF Stop Freq <value> appears in the lower right corner of the AF Spectrum window
Status Bits/OPC
dependencies
Non-overlapped
3.3.7 Marker
Accesses a menu that enables you to select, set up and control the markers for the
current measurement.
Short Range Comms & IoT Mode User's &Programmer's Reference 385
