6 Input/Output

6.7 Output

Connection “-“ pin # “+” pin #

GND 23 48

Stream_MARK_1 24 49

Stream_MARK_2 25 50

Stream_I 16 bit "I" Data

Stream_Q[15:0] 16 bit "Q" Data

Stream_VALID Data valid, when '1' then I/Q data is valid

Stream_CLK 150 MHz DDR clock

Stream_MARK_1 Stream Mark Bit 1

Stream_MARK_2 Stream Mark Bit 2

Stream_ALT currently unused

6.7.5 Data Stream

Lets you choose data or a test pattern to output to the Wideband IF LVDS port. This

can help you set up your streaming target devices.

Remote Command

:OUTPut:DBUS2:DATA MEASure | TEST

:OUTPut:DBUS2:DATA?

Example

:OUTP:DBUS2:DATA TEST

Notes Selecting TEST routes a test pattern to the Wideband Digital Bus stream output

Preset MEAS (set by Restore Input/Output Defaults)

State Saved Saved in Input/Output State

6.7.6 I/Q Cal Out

The Baseband I/Q "Cal Out" port can be turned on with either a 1kHz or a 250kHz

square wave. This can be turned on independent of the input selection. Preset resets

this to OFF.

Remote Command

:OUTPut:IQ:OUTPut IQ1 | IQ250 | OFF

:OUTPut:IQ:OUTPut?

Example

:OUTP:IQ:OUTP IQ1

Dependencies Only available with Option BBA

Couplings An I/Q Cable Calibration or an I/Q Probe Calibration will change the state of the Cal Out port as

needed by the calibration routine. When the calibration is finished the I/Q Cal Out is restored to the

pre-calibration state

Preset

OFF
