4 System

4.6 Alignments

It is suggested to perform Fast Alignment every 8 hours or when temperature has

changed more than 5°C from the previous Fast Alignment.

Remote Command

:CALibration:INTernal:FAST[:ALL]

:CALibration:INTernal:FAST[:ALL]?

Example

:CAL:INT:FAST

Notes The query initiates an Alignment and returns 0 if successful, or 1 if failed

Dependencies Only appears in VXT models M9410A/11A /15A/16A

4.6.2.12 Align LO Leakage

Accesses LO Leakage alignment processes, which are immediate action operations

and perform complete operations, running until they are complete.

This alignment reduce the LO Leakage of the instrument.

Remote Command

:CALibration:INTernal:LOLeakage

:CALibration:INTernal:LOLeakage?

Example

:CAL:INT:LOL

Notes The query initiates an Alignment and returns 0 if successful, or 1 if failed

Dependencies Only appears in VXT models M9410A/11A /15A/16A

4.6.2.13 Align IF Cable

Accesses IF Cable alignment processes, which are immediate action operations and

perform complete operations, running until they are complete.

This alignment aligns the IF cabling to the remote heads.

Remote Command

:CALibration:INTernal:RRHead:IFCable

:CALibration:INTernal:RRHead:IFCable?

Example

:CAL:INT:RRH:IFC

Notes The query initiates an Alignment and returns 0 if successful, or 1 if failed

Dependencies Only appears in VXT based solutions with M1740A/41A/42A/49A/49B RRH

Backwards

Compatibility SCPI

:CALibration:INTernal:IFCable

:CALibration:INTernal:IFCable?

4.6.2.14 Align RRH Amplitude

This is an immediate action operation, which runs until complete.

1819 Short Range Comms & IoT Mode User's &Programmer's Reference
