4 System
4.6 Alignments
Synchronizes RRH LO Clocks.
Remote Command
:CALibration:INTernal:RRHead:LOSync
:CALibration:INTernal:RRHead:LOSync?
Example
:CAL:INT:RRH:LOS?
Notes The query initiates an Alignment and returns 0 if successful, or 1 if failed
Dependencies Only appears in VXT based solutions with M1741A/42A/49A/49B RRH
Backwards
Compatibility SCPI
:CALibration:INTernal:LOSync
:CALibration:INTernal:LOSync?
4.6.2.18 Align VXT Transceiver
In M941xE(M941xA+M9471A) system, accesses alignment processes in VXT
Transceiver(M9410A/11A/15A/16A), which are immediate action operations and
perform complete operations, running until they are complete.
The instrument stops any measurement currently underway, performs the
alignment, then restarts the measurement from the beginning (similar to pressing
the Restart key).
There is no alert available for the VXT Transceiver alignment. Operators are
responsible for checking temperature shift since the last Align VXT Transceiver to
determine whether the VXT Transceiver alignment needs to be executed.
Remote Command
:CALibration:INTernal:VXT:TRANsceiver
:CALibration:INTernal:VXT:TRANsceiver?
Example
:CAL:INT:VXT:TRAN
Notes The query initiates an Alignment and returns 0 if successful, or 1 if failed
Dependencies Only appears on M9410E/11E/15E/16E
4.6.2.19 Align up down converter
In M941xE(M941xA+M9471A) system, accesses alignment processes in up down
converter (M9471A), which are immediate action operations and perform complete
operations, running until they are complete.
The instrument stops any measurement currently underway, performs the
alignment, then restarts the measurement from the beginning (similar to pressing
the Restart key).
There is no alert available for the up down converter alignment. Operators are
responsible for checking temperature shift since the last Align up down converter to
determine whether the up down converter alignment needs to be executed.
1821 Short Range Comms & IoT Mode User's &Programmer's Reference
