Keysight x-series Instruction Manual

4 System
4.6 Alignments
The “Align 20 Hz to 3.6 GHz required” Error Condition appears when this alignment
has expired.You must now perform the Align Now, 20 Hz to 3.6 GHz to keep the
receiver in warrantied operation.
Remote Command
:CALibration:RFPSelector:FULL
:CALibration:RFPSelector:FULL?
Example
:CAL:RFPS:FULL
Notes The query returns 0 if successful, or 1 if failed
When Align 20 Hz to 3.6 GHz is performed, alignment, bit 0 in the Status Operation register is set.
Completion, or termination, clears bit 0 in the Status Operation register
This command is sequential; it must complete before further SCPI commands are processed.
Interrupting the alignment from remote is accomplished by invoking Device Clear, followed by
:ABORt. Successful completion clears bit 1, bit 2 in the Status Questionable Calibration Extended
Needed register and bit 0, bit 1 in Status Questionable Calibration Extended Failure register
A failure encountered during alignment sets the Error Condition “20 Hz to 3.6 GHz Alignment Failure”
and sets bit1, bit 2 in the Status Questionable Calibration Extended Needed register and bit 9 in
Status Questionable Calibration register
Dependencies Does not appear in non-RF Preselector models, setting or querying the SCPI generates an error
Couplings Initializes the time for the Last Align Conducted Now, Conducted Time
Initializes the time for the Last Align Radiated Now, Radiated Time
Records the temperature for the Last Align Conducted Now, Conducted Temperature
Records the temperature for the Last Align Radiated Now, Radiated Temperature
State Saved No
Status Bits/OPC
dependencies
May set Bit 8 or 9 in the Status Questionable Calibration register
May set Bit 1 and 2 in the Status Questionable Calibration Extended Needed register
May set Bit 0 and 1 in the Status Questionable Calibration Extended Failure register
Alert
Enables or disables the display of RF Preselector alignment required message on the
status line. The instrument powers up with Alert ON.
Remote
Command
:CALibration:RFPSelector:ALERt ON | OFF | 0 | 1
:CALibration:RFPSelector:ALERt?
Example
:CAL:RFPS:ALER OFF
Notes Error Condition is generated when alert is ON and any of the RF Preselector alignments has expired
Preset Unaffected by Preset, but set to ON by Restore Defaults >"Alignments" on page 1798
State Saved No
Range
OFF|ON
1871 Short Range Comms & IoT Mode User's &Programmer's Reference

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
