3 Short-Range Comms & IoT Mode

3.10 Spurious Emissions Measurement

n Return Value

Only markers that are enabled are included. <Reserved> items are returned as SCPI_NAN

The data is returned in the current sort order as displayed in the Marker Table

3.10.1 Views

This measurement has two predefined views:

# Name SCPI

1 "Graph + Metrics" on page 1407

RESult

2 "All Ranges" on page 1407

ALL

These are multiple-window views. When in a multiple-window view, you select a

window by touching it. The menu controls may sometimes change, depending on

which window is selected.

Remote Command

:DISPlay:SPURious:VIEW[:SELect] RESult | ALL

:DISPlay:SPURious:VIEW[:SELect]?

Example

:DISP:SPUR:VIEW RANG

:DISP:SPUR:VIEW?

Preset

RESult

State Saved No

Range Graph + Metrics | All Ranges

3.10.1.1 Graph + Metrics

Windows: "Graph" on page 1358,"Table" on page 1359

Select Graph + Metrics to view measurement results.

–

The upper window displays a trace of the range that contains the currently

selected spur

–

The lower window displays a list of spurs detected in a measurement cycle. The

currently selected spur, which is highlighted, can be changed by the Spur

control in the Meas Setup menu

Example

:DISP:SPUR:VIEW RES

3.10.1.2 All Ranges

Windows: "Graph" on page 1358,

Short Range Comms & IoT Mode User's &Programmer's Reference 1357
