3 Short-Range Comms & IoT Mode
3.7 ACP Measurement
Remote Command
:CALCulate:ACPower:MARKer[1]|2|…|12:Y?
Example
:CALC:ACP:MARK11:Y?
Notes Returns the marker Y-axis result, if the control mode is POSition or DELTa. If the marker is OFF,
the response is Not A Number
Dependencies Unavailable when "Meas Method" on page 863 is RBW
Preset Depends on Markers setup and signal source
State Saved No
Backwards
Compatibility SCPI
:CALCulate:ACPower:MARKer[1]|2|…|12:FUNCtion:RESult?
Marker Mode
Sets the marker control mode to POSition (Normal), DELTa, or OFF. All interactions
and dependencies detailed under the control description are enforced when the
remote command is sent. If the selected marker is OFF, pressing Marker sets it to
POSition, and places it at the center of the screen on the trace determined by the
Marker Trace rules. At the same time, Marker X Axis Value appears on the Active
Function area.
The default active function is the active function for the currently selected marker
control mode. If the current control mode is OFF, there is no active function, and the
active function is turned off.
Remote Command
:CALCulate:ACPower:MARKer[1]|2|…|12:MODE POSition | DELTa | OFF
:CALCulate:ACPower:MARKer[1]|2|…|12:MODE?
Example
:CALC:ACP:MARK3:MODE POS
:CALC:ACP:MARK3:MODE?
Dependencies Unavailable when Meas Method is RBW
Preset
OFF
State Saved Saved in instrument state
Range
POSition|DELTa|OFF
Annotation Mkr # <X value> and <Marker value> upper right on graph
Backwards Compatibility SCPI Commands
Sets or queries the state of a marker. Setting a marker that is OFF to ON (1) puts it in
POSition mode and places it at the center of the screen.
Example
:CALC:ACP:MARK2:STAT ON
:CALC:ACP:MARK2:STAT?
Short Range Comms & IoT Mode User's &Programmer's Reference 855
