3 Short-Range Comms & IoT Mode
3.2 Modulation Analysis Measurement
Couplings If Auto Scaling is set to On, the X Width is determined by the trace data
Preset Depends on trace data
State Saved Yes
Min/Max -9.9E+37 / 9.9E+37
Ref Value
Controls the X value of the selected trace at the chosen X Reference Position.
Remote
Command
:DISPlay:EVM:WINDow[1]|2|...|6:X[:SCALe]:RLEVel <real>
:DISPlay:EVM:WINDow[1]|2|...|6:X[:SCALe]:RLEVel?
Example
:DISP:EVM:WIND3:X:RLEV 10
set the X ref value of the third window to 10
:DISP:EVM:WIND3:X:RLEV?
query the X ref value of the third window
Couplings If Auto Scaling is set to On, the X Reference Value is determined by the trace data
Preset Depends on trace data
State Saved Yes
Min/Max -9.9E+37 / 9.9E+37
Ref Position
Determines the position from which the X scaling is calculated for the selected
trace. It can be set to the left side, center, or right side of the grid.
Remote
Command
:DISPlay:EVM:WINDow[1]|2|...|6:X[:SCALe]:RPOSition LEFT | CENTer | RIGHt
:DISPlay:EVM:WINDow[1]|2|...|6:X[:SCALe]:RPOSition?
Example
:DISP:EVM:WIND3:X:RPOS CENT
set the X ref position of the third window to CENT
:DISP:EVM:WIND3:X:RPOS?
query the X ref position of the third window
Couplings If Auto Scaling is set to On, the X Reference Position is determined by the trace data
Preset Depend on trace data
State Saved Yes
Range Left | Ctr | Right
Symbol Interval
Controls how many symbols are used to display in eye diagram window.
Short Range Comms & IoT Mode User's &Programmer's Reference 303
