Keysight x-series Instruction Manual

3 Short-Range Comms & IoT Mode
3.3 LoRa (CSS) Demodulation Measurement
State Saved Saved in instrument state
Min 0.1 Hz
Max 1GHz
Set Reference
Sets the ratio reference value for the RMS ratio’s calculation. This has the same
effect as sending the SCPI command “:DISP:LORA:VIEW:METR:MMAG RMSR”.
Carrier Power Unit
Toggles the unit of the carrier power on the metrics window between watts and
dBm.
Remote Command
:UNIT:LORA:POWer:CARRier DBM | W
:UNIT:LORA:POWer:CARRier?
Example
:UNIT:LORA:POW:CARR DBM
Preset
DBM
State Saved Saved in instrument state
Bar Graph
Toggles the visibility of bars on the traces displayed in the following windows:
frequency drift vs. symbols, demod waveform, RF envelope, and raw demod
waveform.
Remote Command
:DISPlay:LORA:VIEW:BGRaph OFF | ON | 0 | 1
:DISPlay:LORA:VIEW:BGRaph?
Example
:DISP:LORA:VIEW:BGR ON
:DISP:LORA:VIEW:BGR?
Preset
ON
State Saved Yes
Range On|Off
3.3.5.2 View
Contains controls for selecting the current View, and for editing User Views.
Short Range Comms & IoT Mode User's &Programmer's Reference 373
